8 Axis High Speed Spring Coiling Machine
 | Φ1.0-3.0mm Wire Diameter |
 | 8 Axis with External Spring Length Gage Optional |
 | Taiwan Hust Controller&Japan Servo Motor |
 | High Precision&Strong Stability |
 | High Speed Production Rate |
 | Fast Response After-sales Service Team |
Number Of Axis8 axis
Wire Size RangeΦ1.0-3.0 mm
Max. Outside DiameterΦ70 mm
Max. Pitch Of Spring43 mm
Max. Feeding Speed280 m/min
Spring Index3
Feeding Roller Pairs2 pairs
Feeding Motor4.4 kw
Cutter Motor1.3 kw*2
Cam Motor0.85 kw*2
Pitch Motor0.75 kw
Mandrel Moving Up&down Motor1.0 kw
Mandrel Return Motor0.75 kw
Dimension(LxWxH)1000x1400x1900 mm
Weight1200 kgs
